A-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Phase TOC High
PH TOC3 HIGH A PKP
Phase timed overcurrent element pickup Group 3 phase
A
PH TOC3 HIGH A OP
Phase timed overcurrent element operation (trip) Group
3 pha
se A
PH TOC3 HIGH B PKP
Phase timed overcurrent element pickup Group 3 phase
B
PH TOC3 HIGH B OP
Phase timed overcurrent element operation (trip) Group
3 pha
se B
PH TOC3 HIGH C PKP
Phase timed overcurrent element pickup Group 3 phase
C
PH TOC3 HIGH C OP
Phase timed overcurrent element operation (trip) Group
3 pha
se C
PH TOC3 HIGH PKP
Phase timed overcurrent element pickup Group 3 any
pha
se
PH TOC3 HIGH OP
Phase timed overcurrent element operation (trip) Group
3 any pha
se
Phase TOC Low
PH TOC1 LOW A BLK
Phase timed overcurrent element block Low level Group
1 pha
se A
PH TOC1 LOW B BLK
Phase timed overcurrent element block Low level Group
1 pha
se B
PH TOC1 LOW C BLK
Phase timed overcurrent element block Low level Group
1 pha
se C
PH TOC1 LOW A PKP
Phase timed overcurrent element pickup low level
Gr
oup 1 phase A
PH TOC1 LOW A OP
Phase timed overcurrent element operation (trip) low
lev
el Group 1 phase A
PH TOC1 LOW B PKP
Phase timed overcurrent element pickup low level
Gr
oup 1 phase B
PH TOC1 LOW B OP
Phase timed overcurrent element operation (trip) low
lev
el Group 1 phase B
PH TOC1 LOW C PKP
Phase timed overcurrent element pickup low level
Gr
oup 1 phase C
PH TOC1 LOW C OP
Phase timed overcurrent element operation (trip) low
lev
el Group 1 phase C
PH TOC1 LOW PKP
Phase timed overcurrent element pickup low level
Gr
oup 1 any phase
PH TOC1 LOW OP
Phase timed overcurrent element operation (trip) low
lev
el Group 1 any phase
PH TOC2 LOW A BLK
Phase timed overcurrent element block Low level Group
2 pha
se A
PH TOC2 LOW B BLK
Phase timed overcurrent element block Low level Group
2 pha
se B
PH TOC2 LOW C BLK
Phase timed overcurrent element block Low level Group
2 pha
se C
PH TOC2 LOW A PKP
Phase timed overcurrent element pickup low level
Gr
oup 2 phase A
PH TOC2 LOW A OP
Phase timed overcurrent element operation (trip) low
lev
el Group 2 phase A
PH TOC2 LOW B PKP
Phase timed overcurrent element pickup low level
Group 2 phase B
OPERANDS - F650 - MODEL FX - GX
Internal System Status
