A-18 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Ground TOC
GROUND TOC1 BLOCK Ground timed overcurrent element block Group 1
GROUND TOC1 PKP Ground timed overcurrent element pickup Group 1
GROUND TOC1 OP
Ground timed overcurrent element operation (trip)
Gr
oup 1
GROUND TOC2 BLOCK Ground timed overcurrent element block Group 2
GROUND TOC2 PKP Ground timed overcurrent element pickup Group 2
GROUND TOC2 OP
Ground timed overcurrent element operation (trip)
Gr
oup 2
GROUND TOC3 BLOCK Ground timed overcurrent element block Group 3
GROUND TOC3 PKP Ground timed overcurrent element pickup Group 3
GROUND TOC3 OP
Ground timed overcurrent element operation (trip)
Gr
oup 3
Sensitive Ground TOC
SENS GND TOC1 BLOCK
Sensitive ground timed overcurrent element block
Gr
oup 1
SENS GND TOC1 PKP
Sensitive ground timed overcurrent element pickup
Gr
oup 1
SENS GND TOC1 OP
Sensitive ground timed overcurrent element operation
(trip) Gr
oup 1
SENS GND TOC2 BLOCK
Sensitive ground timed overcurrent element block
Gr
oup 2
SENS GND TOC2 PKP
Sensitive ground timed overcurrent element pickup
Gr
oup 2
SENS GND TOC2 OP
Sensitive ground timed overcurrent element operation
(trip) Gr
oup 2
SENS GND TOC3 BLOCK
Sensitive ground timed overcurrent element block
Gr
oup 3
SENS GND TOC3 PKP
Sensitive ground timed overcurrent element pickup
Gr
oup 3
SENS GND TOC3 OP
Sensitive ground timed overcurrent element operation
(trip) Gr
oup 3
Negative Sequence TOC
NEG SEQ TOC1 BLOCK
Negative sequence timed overcurrent element block
Gr
oup 1
NEG SEQ TOC1 PKP
Negative sequence timed overcurrent element pickup
Gr
oup 1
NEG SEQ TOC1 OP
Negative sequence timed overcurrent element
operation Gr
oup 1
NEG SEQ TOC2 BLOCK
Negative sequence timed overcurrent element block
Gr
oup 2
NEG SEQ TOC2 PKP
Negative sequence timed overcurrent element pickup
Gr
oup 2
NEG SEQ TOC2 OP
Negative sequence timed overcurrent element
operation Gr
oup 2
NEG SEQ TOC3 BLOCK
Negative sequence timed overcurrent element block
Gr
oup 3
NEG SEQ TOC3 PKP
Negative sequence timed overcurrent element pickup
Gr
oup 3
NEG SEQ TOC3 OP
Negative sequence timed overcurrent element
operation Group 3
OPERANDS - F650 - MODEL FX - GX
Internal System Status
