APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-23
0x0880 FLT32_038 F003 1.000 R 2
0x0882 FLT32_039 F003 1.000 R 2
0x0884 FLT32_040 F003 1.000 R 2
0x0886 FLT32_041 F003 1.000 R 2
0x0888 FLT32_042 F003 1.000 R 2
0x088A FLT32_043 F003 1.000 R 2
0x088C FLT32_044 F003 1.000 R 2
0x088E FLT32_045 F003 1.000 R 2
0x0890 FLT32_046 F003 1.000 R 2
0x0892 FLT32_047 F003 1.000 R 2
0x0894 FLT32_048 F003 1.000 R 2
0x0896 FLT32_049 F003 1.000 R 2
Maniobras (24 elementos) - Operations
0x0025 0x0400 OPERATION BIT 1 F001 R 1
0x0025 0x0800 OPERATION BIT 2 F001 R 1
... ... ... ... ... ... ... ..
0x0026 0x0002 OPERATION BIT 24 F001 R 1
Eventos de control (128 elementos) - Control Events
0x003D 0x0400 CONTROL EVENT 1 F001 R 1
0x003D 0x0800 CONTROL EVENT 2 F001 R 1
... ... ... ... ... ... ... ...
0x0045 0x0200 CONTROL EVENT 128 F001 R 1
Salidas Virtuales Latcheadas (16 elementos) - Latched virtual outputs
0x0045 0x0400 V.O. Latched 1 F001 R 1
--- --- --- --- --- --- --- ---
0x0045 0x1000 V.O. Latched 3 F001 R 1
0x0046 0x0200 V.O. Latched 16 F001 R 1
Reset Salidas Virtuales Latcheadas - Reset Latched virtual outputs
0x0046 0x0400 Reset V.O. Latched F001 R 1
Entradas Virtuales con sellado (32 elementos) - Virtual Input Latched
0x0083 0x0400 LATCHED VIRT IP 1 F001 R 1
0x0083 0x0800 LATCHED VIRT IP 2 F001 R 1
... ... ... ... ... ... ... ...
0x0085 0x0200 LATCHED VIRT IP 32 F001 R 1
Entradas Virtuales Autoresetables (32 elementos) - Virtual Input Self Reset
0x0085 0x0400 SELF-RST VIRT IP 1 F001 R 1
0x0085 0x0800 SELF-RST VIRT IP 2 F001 R 1
... ... ... ... ... ... ... ...
0x0087 0x0200 SELF-RST VIRT IP 32 F001 R 1
Estado Pantalla - Display Status (does not apply to C650 models)
0x0087 0x0400 GRAPHIC STATUS F001 R 1
0x0087 0x0800 ALARM TEXT ARRAY F001 R 1
Estado Entradas Tarjeta F (32 elementos) - Board F: Contact Input Status
0x0087 0x1000 CONT IP_F_CC1 F001 R 1
0x0087 0x2000 CONT IP_F_CC2 F001 R 1
... ... ... ... .... ... ... ...
0x0089 0x0800 CONT IP_F_CC32 F001 R 1
Estado Señales Activación salidas Tarjeta F (16 elementos) - Board F: Contact Output Operate -logical status-
0x0089 0x1000 CONT OP OPER_F_01 F001 R 1
0x0089 0x2000 CONT OP OPER_F_02 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
