APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-25
0x00D1 0x0010 LED 6 F001 R 1
0x00D1 0x0020 LED 7 F001 R 1
0x00D1 0x0040 LED 8 F001 R 1
0x00D1 0x0080 LED 9 F001 R 1
LEDS HMI (16 elementos) - HMI Leds (cont.)
0x00D2 0x0100 LED 10 F001 R 1
0x00D2 0x0200 LED 11 F001 R 1
0x00D2 0x0400 LED 12 F001 R 1
0x00D2 0x0800 LED 13 F001 R 1
0x00D2 0x1000 LED 14 F001 R 1
0x00D2 0x2000 LED 15 F001 R 1
Teclas HMI - HMI Keys
0x00D2 0x4000 I Key F001 R 1
0x00D2 0x8000 O Key F001 R 1
0x00D2 0x0001 * Key F001 R 1
Señales estado LOCAL/REMOTO para maniobras - LOCAL/REMOTE Operation status signals
0x00D2 0x0002 F1 Key F001 R 1
0x00D2 0x0004 F2 Key F001 R 1
0x00D2 0x0008 LOCAL OPERATION MODE F001 R 1
0x00D2 0x0010 OPERATIONS BLOCKED F001 R 1
Estados Internos - Internal States
0x00D2 0x0020 DSP COMM ERROR F001 R 1
0x00D2 0x0040 MAGNETIC MODULE ERROR F001 R 1
Entrada Reset Leds (configurable) -Led reset Input
0x00D2 0x0080 LED RESET INPUT F001 R 1
Entradas Cambio Estado Local-Remoto-OFF (configurable) - Local-Remote-Off Input selection
0x00D3 0x0100 CHANGE LOCAL-REMOTE F001 R 1
0x00D3 0x0200 CHANGE OP BLOCKED F001 R 1
Entradas Cambio Estado iluminación pantalla (configurable) - Backlight status selection
0x00D3 0x1000 HMI BACKLIGHT ON F001 R 1
0x00D3 0x2000 HMI BACKLIGHT OFF F001 R 1
Estado PLC Fuera de Servicio - Out of Service PLC Status
0x00D4 0x4000 OUT OF SERVICE F001 R 1
0x00D4 0x8000 PLC ERROR F001 R
1
0x00D4 0x0001 General Trip F001 R
1
0x00D4 0x0002 NET CONF ERROR F001 R
1
0x00D4 0x0004 ST HMI BACKLIGHT F001 R
1
0x00D4 0x0008 ORDERCODE ERROR F001 R
1
0x00D4 0x0010 LINK STATUS PORT E F001 R
1
0x00D4 0x0020 LINK STATUS PORT A F001 R
1
0x00D4 0x0040 LINK STATUS PORT B F001 R
1
Estados Sobrecorriente instantanea de fases nivel alto - Phase IOC High States
0x00F2 0x0080 PH IOC1 HIGH A BLK F001 R 1
0x00F3 0x0100 PH IOC1 HIGH B BLK F001 R 1
0x00F3 0x0200 PH IOC1 HIGH C BLK F001 R 1
0x00F3 0x0400 PH IOC1 HIGH A PKP F001 R 1
0x00F3 0x0800 PH IOC1 HIGH A OP F001 R 1
0x00F3 0x1000 PH IOC1 HIGH B PKP F001 R 1
0x00F3 0x2000 PH IOC1 HIGH B OP F001 R 1
0x00F3 0x4000 PH IOC1 HIGH C PKP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
