APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-41
0x03C2 0x0020 LOCKED ROTOR1 PKP F001 R 1
0x03C2 0x0040 LOCKED ROTOR1 OP F001 R 1
0x03C3 0x0080 LOCKED ROTOR2 BLK F001 R 1
0x03C4 0x0100 LOCKED ROTOR2 PKP F001 R 1
0x03C4 0x0200 LOCKED ROTOR2 OP F001 R 1
0x03C5 0x0400 LOCKED ROTOR3 BLK F001 R 1
0x03C5 0x0800 LOCKED ROTOR3 PKP F001 R 1
0x03C5 0x1000 LOCKED ROTOR3 OP F001 R 1
Estados Salidas Remotas DNA - DNA Remote Output Status
0x03E5 0x0008 DNA 1 F001 R 1
0x03E5 0x0010 DNA 2 F001 R 1
... ... ... ... ... ... ... ...
0x03E7 0x0004 DNA 32 F001 R 1
Estados Salidas Remotas Usuario - UserSt Remote Output Status
0x03E7 0x0008 UserSt 1 F001 R 1
0x03E5 0x0010 UserSt 2 F001 R 1
... ... ... ... ... ... ... ...
0x03EB 0x0004 UserSt 64 F001 R 1
Estados Entradas Remotas - Remote Inputs Status
0x03EB 0x0008 Remote Input 1 F001 R 1
0x03EB 0x0010 Remote Input 2 F001 R 1
... ... ... ... ... ... ... ...
0x03ED 0x0004 Remote Input 32 F001 R 1
Estados Dispositivos Remotos - Remote Devices Status
0x03ED 0x0008 Remote Device 1 F001 R 1
0x03ED 0x0010 Remote Device 2 F001 R 1
... ... ... ... ... ... ... ...
0x03EF 0x0400 Remote Device 24 F001 R 1
Estados Sicronizacion Remota - SNTP/IRIG B Status(Do not apply to C650 models)
0x03F2 0x0008 SNTP FAILURE F001 R 1
0x03F2 0x0010 IRIGB FAILURE F001 R 1
0x03F3 0x0001 CNT PULSES FREEZE F001 R
1
0x03F3 0x0002 CNT PULSES UNFREEZE F001 R
1
0x03F3 0x0004 CNT PULSES RESET F001 R
1
Comparadores analógicos-Analog Comparators
0x03F8 0x0020 Analog Level 01 F001 R 1
0x03F8 0x0040 Analog Level 02 F001 R 1
0x03F8 0x0080 Analog Level 03 F001 R 1
0x03F9 0x0100 Analog Level 04 F001 R 1
0x03F9 0x0200 Analog Level 05 F001 R 1
0x03F9 0x0400 Analog Level 06 F001 R 1
0x03F9 0x0800 Analog Level 07 F001 R 1
0x03F9 0x1000 Analog Level 08 F001 R 1
0x03F9 0x2000 Analog Level 09 F001 R 1
0x03F9 0x4000 Analog Level 10 F001 R 1
0x03F9 0x8000 Analog Level 11 F001 R 1
0x03F9 0x0001 Analog Level 12 F001 R 1
0x03F9 0x0002 Analog Level 13 F001 R 1
0x03F9 0x0004 Analog Level 14 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
