B-86 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
1=ENABLED
0x27A8 Pickup Level F003 1 R/W 2
[3 , 300] V
0x27AA Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27AC Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27AE Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27C1 Confirmation address W 1
Ajustes Sobretensión de Neutro Nivel Alto Grupo 3 - Neutral OV High 3 Settings
0x27C2 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27C3 Pickup Level F003 1 R/W 2 [3 , 300] V
0x27C5 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27C7 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27C9 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27DC Confirmation address W 1
Ajustes Sobretensión de Neutro Nivel Bajo Grupo 1 - Neutral OV Low 1 Settings
0x27DD Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27DE Pickup Level F003 1 R/W 2 [3 , 300] V
0x27E0 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27E2 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27E4 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27F7 Confirmation address W 1
Ajustes Sobretensión de Neutro Nivel Bajo Grupo 2 - Neutral OV Low 2 Settings
0x27F8 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x27F9 Pickup Level F003 1 R/W 2 [3 , 300] V
0x27FB Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27FD Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x27FF Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2812 Confirmation address W 1
Ajustes Sobretensión de Neutro Nivel Bajo Grupo 3 - Neutral OV Low 3 Settings
0x2813 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2814 Pickup Level F003 1 R/W 2 [3 , 300] V
0x2816 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2818 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x281A Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x282D Confirmation address W 1
Ajustes Subtensión Auxiliar Grupo 1 - Auxiliary UV 1 Settings
0x282E Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x282F Pickup Level F003 1 R/W 2 [3 , 300] V
0x2831 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
0x2832 Delay F003 1 R/W 2
[0.00 , 900.00] s
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
