B-88 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x28B5 Pickup Level F003 1 R/W 2 [3 , 300] V
0x28B7 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28B9 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28BB Logic F012 1 R/W 1 0=ANY PHASE
1=TWO PHASES
2=ALL PHASES
0x28BC Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x28CF Confirmation address W 1
Ajustes Sobretensión Auxiliar Grupo 1 - Auxiliary OV 1 Settings
0x28D0 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x28D1 Pickup Level F003 1 R/W 2 [3 , 300] V
0x28D3 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28D5 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28D7 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x28EA Confirmation address W 1
Ajustes Sobretensión Auxiliar Grupo 2 - Auxiliary OV 2 Settings
0x28EB Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x28EC Pickup Level F003 1 R/W 2 [3 , 300] V
0x28EE Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28F0 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x28F2 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2905 Confirmation address W 1
Ajustes Sobretensión Auxiliar Grupo 3 - Auxiliary OV 3 Settings
0x2906 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2907 Pickup Level F003 1 R/W 2 [3 , 300] V
0x2909 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x290B Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x290D Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2920 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Secuencia Negativa Grupo 1 - Negative Sequence TOC 1 Settings
0x2921 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2922 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2924 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
To Next Page
