CHAPTER 4: INTERFACES, SETTINGS & ACTUAL VALUES 4.1 ENERVISTA 650 SETUP SOFTWARE
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 4-7
Table 4-1: Types of files generated by EnerVista 650 Setup software, offline:
When using element libraries (both pre-existing in File Library > Open Library or created by the user in File Library > New
Library), the program creates and manages the corresponding files (*.lib) in a folder named FDB (Functional Block
Diagram). These files are used for PLC project compilation. The element library files must be stored with the other logic
configuration files that build the PLC project (*.pep, *.aut, *.lib).
Besides sending configuration information to the relay (Settings & configuration in *.650 format), storing the complete set
of *.650, *.pep, *.aut and *.lib files inside the relay is recommended (Communication > Upload info files to relay). This
ensures that logic configuration files are available in future for logic modifications. Even if these files are not used by the
relay, they are required to connect to the relay and analyze its configuration. The EnerVista 650 Setup software program
manages the logic configuration files globally, so that when the *.pep file is uploaded to the relay, the associated *.aut and
*.lib files are also stored.
Settings & Configuration File *.650
Logic Configuration Files (*.pep, *aut, *.lib)
*.pep *.aut *.lib
Description Settings and Configuration Section Header for Logic
pr
oject
Graphical edition
container. Logic
equations (Virtual
Outputs) in FDB
format.
User programmable
logic object
s
Created by EnerVista 650 Setup Logic configuration
grap
hic editor (PLC
Editor)
Logic configuration
g
raphic editor (PLC
Editor)
Logic configuration
gr
aphic editor (PLC
Editor)
Contents Relay configuration file containing all elements
Settings, input/output and LE
Ds configuration, graphic
display configuration, etc.
Equations corresponding to the logic created and
com
piled in the PLC Editor
PLC project file
cont
aining the
necessary
information
relative to the relay
model, logic
libraries included in
the project (*.lib),
graphic file name
(*.aut), etc.
PLC Project file
c
ontaining all the
drawings used by
the logic, required
by 650 relay based
on IEC 61131-3
standard. Functional
block diagram (FDB).
Library file to be
included
as an
object in a PLC
project. Logic
packages that can
be stored into
libraries and be
distributed in
different PLC
projects.
How to save EnerVista 650 Setup:
File > Save *
PLC Editor:
File > Save Project
PLC Editor:
File > Save Project
PLC Editor:
File > Save Library
How to open EnerVista 650 Setup:
File>Open *
PLC Editor:
File > Open Project
PLC Editor:
File > Open Project
PLC Editor:
File > Library > New
Libra
ry
How to
transfe
r to
relay
Connect with the relay (Communications
> Computer)
Open the created file (Fi
le > Open *)
Send to relay from the menu: File
> Send info to relay
Note that texts used in the configuration of inputs,
output
s, etc. are not sent to the relay. The only texts
sent to relay are operations, events, and LEDs.
Connect with the relay (Communications > Comput
er)
Launch Logic equations Editor (Setp
oint > Logic
Configuration)
Open the created PLC project (F
ile > Open Project)
Compile the project (Run > Compile)
Now the logic (virtual outputs) can be sent directly to relay
(Run > Send
Equations to Relay). Texts of virtual outputs are
not stored in the relay, only in the logic configuration files to
be edited.
File storage inside the relay
(REC
OMMENDED)
Communication > Upload info files to relay through Ethernet
Retrieval of files stored in the relay
(REC
OMMENDED)
Communication > Download info files from relay through Ethernet
