APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-99
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
3=CTL EVENTS 33-48
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
17=BOARD J 1-16
18=BOARD J 17-32
0x2CF4 Binary Input Block 10 F012 1 R/W 1 0=NOT USED
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
3=CTL EVENTS 33-48
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
Ajustes DNP3.0 Esclavo 1 - DNP 3.0 Slave 2 Settings
17=BOARD J 1-16
18=BOARD J 17-32
0x2CF5 Default Analog Map F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x2CF6 Analog Input Point 0 F004 1000 R/W 1 [0 , 32767]
0x2CF7 Analog Input Point 1 F004 1000 R/W 1 [0 , 32767]
0x2CF8 Analog Input Point 2 F004 1000 R/W 1 [0 , 32767]
0x2CF9 Analog Input Point 3 F004 1000 R/W 1 [0 , 32767]
0x2CFA Analog Input Point 4 F004 1000 R/W 1 [0 , 32767]
0x2CFB Analog Input Point 5 F004 1000 R/W 1 [0 , 32767]
0x2CFC Analog Input Point 6 F004 1000 R/W 1 [0 , 32767]
0x2CFD Analog Input Point 7 F004 1000 R/W 1 [0 , 32767]
0x2CFE Analog Input Point 8 F004 1000 R/W 1
[0 , 32767]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
