APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-115
0x2EB1 Stage 2 Tap F003 1 R/W 2 [0.00 , 10000.00] MW
0x2EB3 Stage 2 Time F003 1 R/W 2 [0.00 , 900.00] s
0x2EB5 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2EC8 Confirmation address W 1
Ajustes Unidad de Potencia Máxima Directa Grupo 2 - Forward Power 2 Settings
0x2EC9 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2ECA Blk Time After Close F003 1 R/W 2 [0.00 , 900.00] s
0x2ECC Stage 1 Tap F003 1 R/W 2 [0.00 , 10000.00] MW
0x2ECE Stage 1 Time F003 1 R/W 2 [0.00 , 900.00] s
0x2ED0 Stage 2 Tap F003 1 R/W 2 [0.00 , 10000.00] MW
0x2ED2 Stage 2 Time F003 1 R/W 2 [0.00 , 900.00] s
0x2ED4 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2EE7 Confirmation address W 1
Ajustes Unidad de Potencia Máxima Directa Grupo 3 - Forward Power 3 Settings
0x2EE8 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2EE9 Blk Time After Close F003 1 R/W 2 [0.00 , 900.00] s
0x2EEB Stage 1 Tap F003 1 R/W 2 [0.00 , 10000.00] MW
0x2EED Stage 1 Time F003 1 R/W 2 [0.00 , 900.00] s
0x2EEF Stage 2 Tap F003 1 R/W 2 [0.00 , 10000.00] MW
0x2EF1 Stage 2 Time F003 1 R/W 2 [0.00 , 900.00] s
0x2EF3 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2F06 Confirmation address W 1
Ajustes Demanda - Demand Settings
0x2F07 Demand Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2F08 CRNT Demand Method F012 1 R/W 1 0=THERMAL EXPONENTIAL
1=BLOCK INTERVAL
2=ROLLING DEMAND
0x2F09 POWER Demand Method F012 1 R/W 1 0=THERMAL EXPONENTIAL
1=BLOCK INTERVAL
2=ROLLING DEMAND
0x2F0A Demand Interval F012 1 R/W 1 0=5 Minutes
1=10 Minutes
2=15 Minutes
3=20 Minutes
4=30 Minutes
5=60 Minutes
0x2F0B Trigger Enabled F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2F0C Snapshot Events F012 1
R/W 1 0=DISABLED
1=ENABLED
0x2F1F Confirmation address W 1
Ajustes Protocolo IEC 870-5-104 Settings
0x2F20 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
