c-10 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
C.3 IMPLEMENTATION TABLE APPENDIX C: DNP 3.0 PROTOCOL FOR F650
IMPLEMENTATION TABLE (Sheet 3 out of 3)
Note 1: A default variation refers to the variation responded when variation 0 is requested and/or in class 0, 1, 2, or 3 scans.
Note 2: For static (non-change-event) objects, qualifiers 17 or 28 ar
e only responded when a request is sent with qualifiers 17 or 28,
respectively. Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, are responded to with qualifiers 00 or 01 (for
change-event objects, qualifiers 17 or 28 are always responded).
Note 3: Cold restarts are implemented the same as warm restarts – T
he F650 is not restarted, but the DNP process is restarted.
OBJECT REQUEST RESPONSE
Object
No.
Variation
No.
Description
Function Codes
(dec)
Qualifier Codes (hex) Function Codes
Qualifier Codes
(hex)
34 2
32-Bit Analog Input Reporting
Dea
dband
See Note 1
2 (writ
e)
00,01 (s
tart-stop)
07,08 (
limited qty)
17,28 (i
ndex)
50 0 Time and Date - All Variations 1 (r
ead)
00,01 (s
tart-stop)
06 (no range,
or all)
07,08 (
limited qty)
17,28 (i
ndex)
129 (r
esponse)
00,01 (star
t-
stop)
17,28 (i
ndex)
See Note 2
50 1
Time and Date
See Note 1
1 (r
ead)
2 (writ
e)
00,01 (s
tart-stop)
06 (no range,
or all)
07 (limit
ed qty=1)
08 (limit
ed qty)
17,28 (i
ndex)
129 (r
esponse)
00,01 (star
t-
stop)
17,28 (i
ndex)
See Note 2
52 2 Time Delay Fine
1 (r
ead)
2 (writ
e) 129 (response)
07 (l
imited qty)
quantity=1
60 0 Class 0, 1, 2, and 3 Data
1 (r
ead)
20 (enable u
nsol)
21 (dis
able unsol)
22 (assign class
)
06 (no ran
ge, or all)
60 1 Class 0 Data 06 (no ran
ge, or all)
60 2 Class 1 Data
1 (r
ead)
20 (enable u
nsol)
21 (dis
able unsol)
22 (assign class
)
06 (no ran
ge, or all)
07,08 (l
imited qty)
60 3 Class 2 Data
1 (r
ead)
20 (enable u
nsol)
21 (dis
able unsol)
22 (assign class
)
06 (no ran
ge, or all)
07,08 (l
imited qty)
60 4 Class 3 Data
1 (r
ead)
20 (enable u
nsol)
21 (dis
able unsol)
22 (assign class
)
06 (no ran
ge, or all)
07,08 (l
imited qty)
80 1 Internal Indications 2 (writ
e)
00 (st
art-stop)
(index must =7)
No Object (function code only)
See Note 3
13 (cold r
estart)
No Object (function code only) 14 (w
arm restart)
No Object (function code only) 23 (delay m
eas.)
