c-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
C.5 DNP CONFIGURATION EXAMPLES APPENDIX C: DNP 3.0 PROTOCOL FOR F650
C.5.3 Multiple DNP 3.0 masters communication with F650
Typical architecture of multi-master communication using DNP 3.0.
Figure C-3: Multiple DNP3.0 masters communicating with F650
41 Not Configured
42 Not Configured
43 Not Configured
44 Not Configured
45 Not Configured
46 Not Configured
47 Not Configured
