D-14 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
D.6 IEC 60870-5-104 INTEROPERABILITY APPENDIX D: IEC 60870-5-104 PROTOCOL
Information object address
(system-specific parameter, all configurations that are used are to be marked "X")
Cause of transmission
(system-specific parameter, all configurations that are used are to be marked "X")
Length of APDU
(system-specific parameter, specify the maximum length of the APDU per system)
The maximum length of APDU for both directions is 253. It is a fixed system parameter.
Selection of standard ASDUs
Process information in monitor direction
(station-specific parameter, mark each Type ID “X” if it is only used in the standard direction, "R" if only used in
the reverse direction, and “B” if used in both directions).
