APPENDIX D: IEC 60870-5-104 PROTOCOL D.6 IEC 60870-5-104 INTEROPERABILITY

GEK-106310-AF F650 DIGITAL BAY CONTROLLER d-19

Basic application functions

Station initialization

(station-specific parameter, mark "X" if function is used)

Cyclic data transmission

(station-specific parameter, mark “X” if function is only used in the standard direction, "R" if only used in the

reverse direction, and "B" if used in both directions)

Read procedure

(station-specific parameter, mark "X" if function is only used in the standard direction, "R" if only used in the

reverse direction, and "B" if used in both directions)

Spontaneous transmission

(station-specific parameter, mark “X” if function is only used in the standard direction, "R" if only used in the

reverse direction, and “B” if used in both directions)

<101> C_CI_NA_1

X X X

<102> C_RD_NA_1

<103> C_CS_NA_1

X X

<104> C_TS_NA_1

<105> C_RP_NA_1

X X

<106> C_CD_NA_1

<107> C_TS_TA_1

<110> P_ME_NA_1

<111> P_ME_NB_1

<112> P_ME_NC_1

X X X

<113> P_AC_NA_1

<120> F_FR_NA_1

<121> F_SR_NA_1

<122> F_SC_NA_1

<123> F_LS_NA_1

<124> F_AF_NA_1

<125> F_SG_NA_1

<126> F_DR_TA_1*

<127> F_SC_NB_1*

* Blank or X only

Remote initialization

Cyclic data transmission

Read procedure

Spontaneous transmission
