Table 54. DIMM slots populated with the memory RDIMM
Processor Memory Channel DIMM Slot Number
1 0 1 - 16GB RDIMM
2 - 2GB RDIMM
1 4 - 16GB RDIMM
5 - 2GB RDIMM
2 12 - 16GB RDIMM
11 - 2GB RDIMM
3 9 - 16GB RDIMM
8 - 2GB RDIMM
2 0 13 - 16GB RDIMM
14 - 2GB RDIMM
1 16 - 16GB RDIMM
17 - 2GB RDIMM
2 24 - 16GB RDIMM
23 - 2GB RDIMM
3 21 - 16GB RDIMM
20 - 2GB RDIMM
Note: Do not put any DIMM into DIMM slots 3, 6, 7, 10, or slots 13 to 24.
Procedure
1. Remove the air baffle over the DIMMs (see “Removing the air baffle” on page
137).
2. Open the retaining clip on each end of the DIMM connector.
Attention: To avoid breaking the retaining clips or damaging the DIMM
connectors, open and close the clips gently.
3. Touch the static-protective package that contains the DIMM to any unpainted
metal surface on the file module, and then remove the DIMM from the
package.
4. Turn the DIMM so that the DIMM keys align correctly with the connector.
5. Insert the DIMM into the connector by aligning the edges of the DIMM with
the slots at the ends of the DIMM connector. Firmly press the DIMM straight
down into the connector by applying pressure on both ends of the DIMM
simultaneously. The retaining clips snap into the locked position when the
DIMM is firmly seated in the connector.
Attention: If there is a gap between the DIMM and the retaining clips, the
DIMM has not been correctly inserted; open the retaining clips, remove the
DIMM, and then reinsert it.
6. Repeat steps 1 through 5 until all the new or replacement DIMMs are
installed.
7. Replace the air baffle over the DIMMs (see “Installing the air baffle” on page
138), making sure all cables are out of the way.
8. Install the cover (see “Installing the cover” on page 124).
9. Slide the file module into the rack.
Chapter 4. File module 155
