IBM Storwize V7000 Unified Problem Determination Guide

Table 89. Understanding the node canister status LEDs
LED state
Description
Power
(green)
Fault (amber)
System
status (green)
Off
(any) (any)
Power is not being provided by any power supply unit (PSU)
in the enclosure, or power is coming from the battery in the
canister.
If at least one PSU is powering the enclosure, the canister or
the enclosure midplane might be faulty.
If both node canisters in an enclosure indicate this state at
the same time, it is more likely that the enclosure midplane is
faulty. Reseat any node canister in this state, as described in
“Procedure: Reseating a Storwize V7000 Gen2 node canister”
on page 278. If the condition persists, replace the node
canister. If just one canister is affected, see “Replacing a
Storwize V7000 Gen2 node canister” on page 295. If both
canisters are affected, see “Replacing a Storwize V7000 Gen2
control enclosure midplane assembly” on page 352.
Flashing slowly
Power is available, but the canister is powered off. (The main
CPU is not running.)
Restart the node canister, as described in “Procedure:
Reseating a Storwize V7000 Gen2 node canister” on page 278.
Flashing fast
The node canister is doing a self test during start-up.
Wait for the canister to complete its start-up sequence.
258 Storwize V7000 Unified: Problem Determination Guide 2073-720

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
