Table 15. Storwize V7000 2076-524 battery status LEDs
Name Call out Color State Meaning
Battery status ▌5▐ Green OFF Indicates the
battery is not
available for use
(e.g., battery is
missing or there
is a fault in the
battery).
FAST BLINK The battery has
insufficient
charge to
complete a fire
hose dump.
BLINK The battery has
sufficient charge
to complete a
single fire hose
dump.
ON The battery has
sufficient charge
to complete at
least two fire
hose dumps.
Battery fault ▌6▐ Amber OFF No fault. An
exception to this
would be where
a battery has
insufficient
charge to
complete a
single fire hose
dump. Refer to
the
documentation
for the Battery
status LED.
ON There is a fault
in the battery.
Storwize V7000 2076-524 node canister system status LEDs
Table 16 on page 19 show system status LEDs and their location in Figure 22 on
page 15.
18 Storwize V7000 Unified: Problem Determination Guide 2073-720
