IBM Storwize V7000 Unified Problem Determination Guide

Table 14. Storwize V7000 2076-524 SAS ports 1 and 2 LEDs (continued). Storwize V7000
2076-524 SAS ports 1 and 2 LED legend.
Name Call out Symbol Color State Meaning
SAS Port 2
Link
▌3▐ None Green OFF No link
connection on
any phys
(lanes). The
connection is
down.
ON There is a
connection on
at least one
phy. At least
one of the
lanes to that
connector is
up.
SAS Port 2
Fault
▌4▐ None Amber OFF No fault. All
four phys
have a link
connection.
ON This can
indicate a
number of
different error
conditions:
v One or
more, but
not all, of
the 4 phys
are
connected.
v Not all 4
phys are at
the same
speed.
v One or
more of the
connected
phys are
attached to
an address
different
from the
others
Storwize V7000 2076-524 node canister battery status LEDs
Table 15 on page 18 show battery status LEDs and their location in Figure 22 on
page 15.
Chapter 1. Storwize V7000 Unified hardware components 17

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
