IBM Storwize V7000 Unified Problem Determination Guide

▌1▐ Power supply unit 1
▌2▐ Power supply unit 2
▌3▐ Canister 1
▌4▐ Canister 2
▌1▐ Node canisters
▌2▐ Power supply units
Power supply units for control enclosures
Storwize V7000 Unified enclosures use different power supply units, depending on
the generation of your control enclosure model.
Storwize V7000 Unified Gen1 refers to the enclosure models in the following table:
1
2
3
svc00662
4
Figure 14. Rear view of a model 2076-112 or a model 2076-124 control enclosure
1
3
2
4
svc00726
5
Figure 15. Rear view of a model 2076-312 or a model 2076-324 control enclosure
1
2
3
svc00610
4
Figure 16. Rear view of a model 2076-212 or a model 2076-224 expansion enclosure
Chapter 1. Storwize V7000 Unified hardware components 9

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
