IBM Storwize V7000 Unified Problem Determination Guide

Table 24. Node canister LEDs (continued)
Name Description Color Symbol
Fault Indicates if a fault is present and identifies which
canister.
v The on status indicates that the node is in service
state or an error exists that might be preventing the
code from starting. Do not assume that this status
indicates a hardware error. Further investigation is
required before replacing the node canister.
v The off status indicates that the node is a candidate
or is active. This status does not mean that there is
not a hardware error on the node. Any error that
was detected is not severe enough to stop the node
from participating in a system.
v The flashing status indicates that the canister is
being identified. This status might or might not be
a fault.
Amber
Power Indicates if power is available and the boot status of
the canister.
v The on status indicates that the canister is powered
on and that the main processor or processors are
running.
v The off status indicates that no power is available.
v The slow flashing (1 Hz) status indicates that power
is available and that the canister is in standby
mode. The main processor or processors are off and
only the service processor is active.
v The fast flashing (2 Hz) indicates that the canister is
running the power-on self-test (POST).
Green
Notes:
1. If the system status LED is on and the fault LED is off, the node canister is an active
member of a system.
2. If the system status LED is on and the fault LED is on, there is a problem establishing a
system.
For a more complete identification of the system LEDs, go to “Procedure: Understanding
the Storwize V7000 Gen1 system status using the LEDs” on page 262.
Expansion canister ports and indicators
An expansion canister is one of two canisters that is located in the rear of the
expansion enclosure. The expansion canister has no controls.
There is a diagnostic port on the right of the expansion canister. There are no
indicators that are associated with the port. There are no defined procedures that
use the port.
Storwize V7000 Gen2 expansion canister SAS ports and
indicators
Two SAS ports are located in the rear of the Storwize V7000 Gen2 expansion
canister.
Chapter 1. Storwize V7000 Unified hardware components 31

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
