IBM Storwize V7000 Unified - Removing and Replacing Parts for the 2073-720; Components Identified as Customer Replaceable Units (Crus) and Field Replaceable Units (Frus)

Removing and replacing parts for the 2073-720
About this task
Illustrations in this section might differ slightly from the actual hardware.
Table 53. Components identified as customer replaceable units (CRUs) and field
replaceable units (FRUs)
Types of
replaceable
parts
Explanation of
each type of
replaceable part
Procedures categorized under each type of
replaceable part
Tier 1 Customer
replaceable units
(CRUs)
Tier 1 CRUs are
your responsibility.
If IBM installs a
Tier 1 CRU at your
request, you will
be charged for the
installation.
Service agreements
can be purchased
so that you can
ask IBM to replace
these.
“Removing the cover” on page 123
“Installing the cover” on page 124
“Removing the bezel” on page 125
“Installing the bezel” on page 126
“Disk drive cable connections” on page 129
“Removing the battery” on page 131
“Installing the battery” on page 135
“Removing the air baffle” on page 137
“Installing the air baffle” on page 138
“Removing the fan bracket” on page 139
“Installing the fan bracket” on page 140
“Removing a PCI riser-card assembly” on page 141
“Installing a PCI riser-card assembly” on page 142
“Removing a PCI adapter from a PCI riser-card
assembly” on page 143
“Installing a PCI adapter in a PCI riser-card
assembly” on page 145
“Removing a Fibre Channel PCI adapter” on page
146
“Installing a Fibre Channel PCI adapter” on page
146
“Removing a 10-Gbps Ethernet adapter” on page
146
“Installing a 10-Gbps Ethernet adapter” on page 147
“Removing a hot-swap hard disk drive” on page
148
“Installing a hot-swap hard disk drive” on page 149
“Removing the DVD drive” on page 150
“Installing the DVD drive” on page 152
“Removing a memory module” on page 152
“Installing a memory module” on page 153
“Removing a hot-swap fan” on page 156
“Installing a hot-swap fan” on page 157
“Removing a hot-swap ac power supply” on page
158
“Installing a hot-swap ac power supply” on page
159
“Removing the operator information panel
assembly” on page 162
“Installing the operator information panel assembly”
on page 163
“Removing the hot-swap drive backplane” on page
164
“Installing the hot-swap drive backplane” on page
165
“Removing the 240 VA safety cover” on page 127
122 Storwize V7000 Unified: Problem Determination Guide 2073-720
