Table 116. Replacing host interface adapters in two control enclosures concurrently
Control enclosure 1 Control enclosure 2
Node canister 1 Node canister 2 Node canister 1 Node canister 2
Step 1 Step 1
Step 2 Step 2
... ...
Final step Final step
Step 1 Step 1
Step 2 Step 2
... ...
Final step Final step
Replacing a CMOS battery
Remove and replace the complementary metal-oxide semiconductor (CMOS)
battery.
Replacing a Storwize V7000 Gen2 CMOS battery
The complementary metal-oxide semiconductor (CMOS) battery is a coin-shaped
power cell that is mounted inside a node canister. It is used to keep the system
time when there is no power to the node canister. The lithium battery must be
handled correctly to avoid possible danger. If you replace the battery, you must
adhere to all safety instructions.
About this task
Use this procedure to replace a CMOS battery. Dispose of the faulty battery
properly.
CAUTION: If your system has a module containing a lithium battery, replace it
only with the same module type made by the same manufacturer. The battery
contains lithium and can explode if not properly used, handled, or disposed of.
Do not:
v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble
Dispose of the battery as required by local ordinances or regulations. (C045)
Procedure
1. Complete “Procedure: Removing a Storwize V7000 Gen2 node canister” on
page 279
2. Open the canister and remove the lid as described in “Procedure: Removing
and replacing the lid of a Storwize V7000 Gen2 node canister” on page 285.
3. Locate the CMOS battery inside the node canister.. See Figure 119 on page 375
374 Storwize V7000 Unified: Problem Determination Guide 2073-720
