IBM Storwize V7000 Unified Problem Determination Guide

Table 104. Storwize V7000 Unified Gen2 model numbers
Machine
type/model Description
2076-524 Storwize V7000 Unified control enclosure, with up to 24 2.5-inch (6.35
cm) drives
2076-12F Storwize V7000 Unified expansion enclosure for up to 12 3.5-inch (8.89
cm) drives
2076-24F Storwize V7000 Unified expansion enclosure for 2.5-inch drives
Storwize V7000 2076-524 Gen2 replaceable units
You might have to replace a Storwize V7000 2076-524 part. Some replaceable parts
are customer-replaceable units (CRUs) and some are field-replaceable units (FRUs),
which are replaced by IBM trained service technicians.
Table 105. Control enclosure replaceable units
Part number Part name CRU or FRU Notes
31P1854 Control enclosure
midplane assembly
FRU Excludes drives,
drive blanks,
canisters, fan
modules, bezel
covers, PSUs.
31P1845 Node canister CRU Includes 2x 16 GB
DIMMs, system
drive, CMOS battery.
Excludes Node
battery, interface
adapters,
compression
adapter/passthrough.
31P1849 Control enclosure
power supply unit
CRU
31P1847 Fan module CRU
45W8680 Drive blank, 2.5-inch
form factor
CRU
31P1851 Control enclosure left
bezel
CRU No MTM/Serial
number label on the
FRU.
00Y2512 2.5-inch enclosure
right bezel
CRU
31P1856 Control enclosure rail
kit
CRU
31P1807 Node battery CRU
64P8453 Node canister
memory (16 GB
DIMM)
CRU
33F8354 CMOS coin battery CRU For real-time clock
31P1861 Compression
pass-through adapter
CRU
31P1863 Compression
accelerator
CRU
288 Storwize V7000 Unified: Problem Determination Guide 2073-720

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
