IBM Storwize V7000 Unified Problem Determination Guide

5. Using the handle, gently slide the power supply out of the enclosure, as shown
in Figure 89.
6. Hold the new power supply so that the handle is fully extended.
7. Slide the power supply into the enclosure until it stops. Rotate the handle
upward into the closed position until it clicks.
8. Hold the new power supply so that the handle is fully extended.
9. Connect the power cord to the power supply and to a properly grounded
electrical outlet.
Note: After the power cord is connected to the electrical outlet, make sure that
the ac and dc power (green) LEDs are lit and the fault (amber) LED is off.
Replacing a power supply unit for an expansion enclosure
You can replace either of the two 580 watt hot-swap redundant power supplies in
the expansion enclosure. These redundant power supplies operate in parallel, one
continuing to power the canister if the other fails.
Figure 89. Removing the power supply unit from the left side of the expansion enclosure
Chapter 5. Control enclosure 311

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
