IBM Storwize V7000 Unified Problem Determination Guide

Table 64. XML statistics for an IP Partnership port (continued)
Statistic
name Description
iprx Indicates the bytes received from other nodes in other clusters by the IP
partnership driver.
ipsz Indicates the average size (in bytes) of data that are being transmitted by the
IP partnership driver since the last statistics collection period.
iptx Indicates the bytes transmitted to other nodes in other clusters by the IP
partnership driver.
Actions
The following actions are available to the user:
OK Click this button to change statistic collection.
Cancel
Click this button to exit the panel without changing statistic collection.
XML formatting information
The XML is more complicated now, as seen in this raw XML from the volume
(Nv_statistics) statistics. Notice how the names are similar but because they are in
a different section of the XML, they refer to a different part of the VDisk.
<vdsk idx="0"
ctrs="213694394" ctps="0" ctrhs="2416029" ctrhps="0"
ctds="152474234" ctwfts="9635" ctwwts="0" ctwfws="152468611"
ctwhs="9117" ctws="152478246" ctr="1628296" ctw="3241448"
ctp="0" ctrh="123056" ctrhp="0" ctd="1172772"
ctwft="200" ctwwt="0" ctwfw="3241248" ctwfwsh="0"
ctwfwshs="0" ctwh="538" cm="13768758912876544" cv="13874234719731712"
gwot="0" gwo="0" gws="0" gwl="0"
id="Master_iogrp0_1"
ro="0" wo="0" rb="0" wb="0"
rl="0" wl="0" rlw="0" wlw="0" xl="0">
Vdisk/Volume statistics
<ca r="0" rh="0" d="0" ft="0"
wt="0" fw="0" wh="0" ri="0"
wi="0" dav="0" dcn="0" pav="0" pcn="0" teav="0" tsav="0" tav="0"
pp="0"/>
<cpy idx="0">
volume copy statistics
<ca r="0" p="0" rh="0" ph="0"
d="0" ft="0" wt="0" fw="0"
wh="0" pm="0" ri="0" wi="0"
dav="0" dcn="0" sav="0" scn="0"
pav="0" pcn="0" teav="0" tsav="0"
tav="0" pp="0"/>
</cpy>
<vdsk>
The <cpy idx="0"> means its in the volume copy section of the VDisk, whereas the
statistics shown under Vdisk/Volume statistics are outside of the cpy idx section
and therefore refer to a VDisk/volume.
Similarly for the volume cache statistics for node and partitions:
Chapter 5. Control enclosure 225
