Table 29: M40e or M160 Router Chassis Component Alarm

Conditions (continued)

Alarm

SeverityRemedyAlarm Condition

Chassis

Component

Red----------------------------------Too many hot-swap interrupts

are occurring. This message

generally indicates that a

hardware component that plugs

into the router’s backplane from

the front (generally, an FPC) is

broken.

Hot swapping

YellowReplace the failed

MCS.

An MCS has an out-of-range or

invalid temperature reading.

MCS

YellowReinstall MCS0.An MCS was removed.

RedReplace the failed

MCS.

An MCS has failed.

YellowSet the backup PCG

online.

A backup PCG is offline.PCG

YellowReplace the failed

PCG.

A PCG has an out-of-range or

invalid temperature reading.

YellowInsert a PCG into

empty slot.

A PCG was removed.

RedReplace the failed

PCG.

A PCG failed to come online.
