A-35
A-4List of Alarm/Warning Messages
APPENDIX
- SV Series User’s Manual -
D01
Excessive error at servo on 1
(Excessive ErrorAtSvon1)
Position deviation at servo ON exceeds deviation excessive
alarm level "ALM_10".
Position deviation pulse is not cleared at servo OFF, and
motor rotates and is in servo ON status at excessive
accumulated position deviation pulse. Please clear position
deviation at servo OFF or re-check and change the set value
of deviation excessive alarm level "ALM_10" at servo ON.
G1
○○
D02
Excessive error at servo on 2
(Excessive ErrorAtSvon2)
Position deviation exceeds deviation excessive alarm level
"ALM_07".
Servo is ON when position deviation pulse is accumulated
during servo OFF, and deviation excessive alarm level
"ALM_07" is exceeded since command pulse is input during
operation with speed limit "ALM_12" at servo ON. Please set
deviation excessive alarm level "ALM_07" or speed limit at
servo ON "ALM_012" to proper value.
G2
○○
E02
COM alarm 1
(WDC+SyncFlag sync error)
(COM Alarm 1)
Transform cycle error occurs in MECHATROLINK-II
communication.
Please check the main reason for transform cycle change of
higher-level equipment.
Please contact the nearest sales agent of our company when
the founded problem can't be solved even if the power supply
of control circuit is ON again.
G1
○
-
E40
ML-II transform cycle
setting error
(ML2TransCycle Setting
Err)
Sync error occurs in MECHATROLINK-II communication.
Transform cycle setting error occurs for MECHATROLINK-II
communication.
Please check the set value of transform cycle.
G2
○
-
E50
ML-II sync error (ML2 Sync
Err)
Sync error occurs in communication.
Please check whether the WDT data of higher-level
equipment is updated rightly.
ML-II sync error (E50) isn't saved in alarm log.
G2
○
-
E51
ML-II sync failed (ML2
Sync Failed)
Sync communication start is failed.
Please check whether the WDT data of higher-level
equipment is updated rightly.
G2
○
-
E60
ML-II comm error
- receive error (ML2
Comm Error)
Contineous communication error occurs in MECHATROLINK-
II communication. Please check and solve the following
problems.
(1) Please wire MECHATROLINK-II communication cables
correctly and install terminator rightly.
(2)
Please take measures to control noise. (Check wiring and
grounding of communication cables. Or install ferrite core on
communication cables.)
ML-II comm error (E60) isn't saved in alarm log.
G2
○
-
E61
ML-II transform cycle error
-sync interval error
(ML2TransCycle Error)
Transform cycle error occurs in MECHATROLINK-II
communication.
Please check the main reason for transform cycle change of
higher-level equipment.
G2
○
-
ED1
Command execute timeout
(Cmd Execute Timeout)
Timeout error occurs for MECHATROLINK-II communication
command. Please check whether the commands of SV_ON
and SENS_ON are executed during motor rotation.
G2
○
-
EA2
COM alarm 2
servo WDC error
(COM Alarm 2)
Transform cycle error occurs in MECHATROLINK-II
communication.
Please check the main reason for transform cycle change of
higher-level equipment.
Please contact the nearest sales agent of our company when
the founded problem can't be solved even if the power supply
of control circuit is ON again.
G2
○○
F10
Main circuit open phase
(Main Circuit Open Phase)
Lower voltage of one of L1, L2 and L3 phase lasts over one
second when power supply of main circuit is ON.
(1) The set value of three/single-phase power supply
"OTH_11" is different from the type of actual input power
supply (three/single-phase). Please check set value and
type of input power supply.
(2) The wiring of three-phase power supply is poor or three
phase isn't balanced. Please check whether there are
problems in the wiring of three-phase power and the
balance of power supply.
G2
○○
*1 For alarm marked with "*",control circuit power needs to be restarted after setup.
*2 For details about stop method, see "5-2 Common Function Setting", Page 5-4.
*3 ML-II is the short name for MECHATROLINK-II and PLS the pulse/analog input type.
Alarm code
Alarm
*1
(words in () dislayed
in Access Window)
Alarm description and Correction
Stop
method
*2
Enable type
*3
ML-II PLS
