4-32
SIGNALS AND WIRING
4
4-5 Wiring I/O Signals
- SV Series User’s Manual -
<Min. response waveform>
Min. response waveform of line driver
ƽ1-phase (1-pulse/2-pulse)
T
T
T1
T3
T2
T4
T2T1
ON
ON
ON
OFF
OFF
A-phase
B-phase
50%
50%
50%
OFF
ƽPhase difference (2-phase 1X/2-phase 2X/2-phase 4X)
Pulse train input filter: up to 4MHz
T : > 0.25μs
T1, T2 : > 0.1μs
T : > 1μs
T1, T2 : > 0.4μs
Pulse train input filter:
˖
up to 1MHz
T : > 1μs
T1, T2, T3, T4 : > 0.15μs
ƽ1-phase (1-pulse/2-pulse)
T
T
T2T1
A-phase
B-phase
T : > 5μs
T1, T2 : > 2μs
T : > 5μs
T1, T2, T3, T4 : > 0.75μs
Min. response waveform of open collector
ON
ON
ON
OFF
OFF
50%
50%
50%
OFF
ƽPhase difference (2-phase 1X/2-phase 2X/2-phase 4X)
T1
T2
T3
T4
