4-82 Options Service Manual
4024-XXX
9. Remove the two screws securing the lower guide (C) to the media feed unit assembly (A).
10. Remove the lower guide (C).
11. Remove two screws securing the upper guide (D) to the media feed unit assembly (A).
12. Remove the upper guide (D).
13. Remove two screws securing the rear bracket (E) to the media feed unit assembly (A).
14. Remove the rear bracket (E).
C
D
E
