Rev. 1
Page 3-
16
LCD INDICATION Alarm description Effect/Signaling
Possible cause / Check
Proposed solution
Check manually the operation of the locking
micro-switch pin.
- Adjust the micro-switch.
- Replace the micro-switch- see card Gr6-5.
Check with a tester the 1,25 A fuse
- Replace the fuse (same value).
- Replace the electronic board - see card Gr1-1.
Check for the correct fastening of the motor
mounting screws.
- Restore the correct mounting.
- Replace the motor - see card Gr6-6.
- Replace the motor pin- see card Gr6-6.
Check for the free turning of the fork
bushes.
- Replace the blocked bush- see card Gr6-3.
Check that the motor runs normally.
The locking mechanism is step-working.
- Replace the pin- see card Gr6-6.
- Replace the motor- see card Gr6-6.
Check the 2 A fuse on the power board
- Replace the fuse - see card Gr1-16.
Enter the setup, go to SERVICE and then
select the option LOCKING DEVICE in
order to check the door locking mechanism.
- Replace the burned fuse- see card Gr1-16.
- Replace the power board- see card Gr1-1.
Door gasket replacement by the user.
- Remove and mount properly the gasket.
- Replace the door gasket - see card Gr6-1
- Check the parabola adjustment.
- Replace the parabola- see card Gr6-2
