PIPES AND FITTINGS
– 6x12 sheathed 110#000005W0
– 6x10 transparent 110#000003W0
– 4X7 transparent 110#000011W0
– 6x12 sheathed 110#000014W0
– 4X2,5 PFTE 110#000002W0
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
TRANSPARENT PIPES
The replacement of transparent pipes should be performed by taking care to follow
the previous pipe path in order to not change its performance.
Fasten the pipe with plastic clips.
SHEATHED PIPES
The replacement of sheathed pipes should be performed by taking care to follow the
previous pipe path and length.
Fasten the 6x12 pipes by metallic clips.
The 2.5x5 pipes are used to connect fitting provided with locknut.
FITTING
Unplug the pipe from the fitting before removing the latter, and clean the thread.
Use a sealing product on the thread before screwing again the fitting in its seat.
