Rev. 1
Card Gr1-
18
MAIN SWITCH
420#00070000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Remove the wiring (1) from the switch;
3. Remove the mains switch (2);
4. Mount the new switch, restore connections and assembly all items
proceeding in reverse order as above;
5. Run a sterilization cycle.
12
