Rev. 1
Card Gr4-
8
SAECO FILTER ON THE WATER PUMPS
472#00020000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Empty the distilled water reservoir;
3. Cut the nylon clamp on the Saeco filter (1) and remove it;
4. Mount the new filter, assembly all items and restore connections proceeding
in reverse order as above;
5. Run a sterilization cycle.
1
