Rev. 1
Card Gr5-
6
MOTOR AND PRESSURE SWITCH
A#2BG3520000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Remove the cover plate under the frame to access the ratio-motor;
3. Disconnect the wiring from the ratio-motor, pressure switch and power board;
4. Replace the wiring, restore connections and assembly all items proceeding in
reverse order as above;
5. Run a sterilization cycle.
