Mocom millennium B - STEAM GENERATOR GROUND WIRE

Rev. 1
Card Gr5-
7
STEAM GENERATOR GROUND WIRE
A#2BP2310000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Remove the steam generator (see card Gr4-6 );
3. Disconnect the grounding wire from the steam generator and frame;
4. Replace the wiring, restore connections and assembly all items proceeding in
reverse order as above;
5. Run a sterilization cycle.
