Rev. 1
Card Gr1-
6
PRESSURE SWITCH
431#00060000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1);
2. Remove the wiring from the pressure switch;
3. Remove the two screws fixing the pressure switch to the plate;
4. Mount the new pressure switch, restore connections and assembly all items
proceeding in reverse order as above;
5. Run a sterilization cycle.
