SEQUENCE OF THE PROCESS
It follows the description of the sterilization cycle, phase by phase. As example, we will use the most complete and meaningful cycle, i.e. the cycle
relating the program 134°C POROUS (preset 1 on the control panel), provided with fractionated pre-vacuum.
Standby status
Counter xxxxx/yyyyy
Stand-by HIGH
23.6 °c 30/08/02
-0.01 bar 18:13:05
CHAMBER
Water
tank
DESCRIPTION STATUSES PV PA
EV1
(no)
EV2
(nc)
EV3
(nc)
EV4
EV5
(no)
EV6
(nc)
Fan
STAND-BY
Standby
(door closed)
OFF OFF OFF OFF OFF OFF OFF OFF
1’ ON
6’ OFF
