Rev. 1
Card Gr2-
4
EV4 VALVE / COIL / SHAFT
401#00260000
EV4 ASSEMBLY
A#0BP2840000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Remove the wiring and the sheathed pipes from the valve;
3. Remove the EV4 group from the support;
4. Disassembly the group as necessary (see figure) and replace the involved
part;
5. Remount all parts, restore connections proceeding in reverse order as above;
6. Run a sterilization cycle.
