Mocom millennium B - SEQUENCE OF THE PROCESS; Steam discharge

Rev. 1
Page 2-
20
Steam discharge
At the end of the sterilization phase, the steam is released from the sterilization chamber (STEAM DISCHARGE). The liquid crystal display
shows:
1 134°C POROUS
DEPRESSURIZATION
123.9 °C
1.24 bar 18:20
The icon for the sterilization process status
is steady on.
Water
tank
DESCRIPTION
STATUSES
(P, t)
VP WP
EV1
(no)
EV2
(nc)
EV3
(nc)
EV4 EV5
(no)
EV6
(nc)
Fan
from +2,15/1,12 to +0,10 bar ON OFF ON ON OFF ON ON OFF ON
from +0,10 to +0,10 bar ON OFF ON OFF OFF ON ON OFF ON
Steam discharge
from +0,20 to -0,00 bar ON OFF OFF OFF ON ON ON OFF ON
