CONNECTING AN EXTERNAL WATER FILLING TANK
(OPTIONAL, automatic filling function)
To avoid having to periodically fill the water tank (see First start-up), it is possible to connect the sterilizer to an external filling tank (supplied as
an option), that the user will periodically fill, or to a commercially-available, reverse-osmosis water purification system with accumulation tank.
In that case, when the internal water tank reaches the MIN level, the autoclave activates a pump that automatically fills the internal tank.
Follow the instructions below for the correct connection of the external tank:
– Install the tap provided on the filling tank; use Teflon tape or connector sealant for a perfect seal .
– Use the filling tanks silicone tube (or other suitable tube, max length 2 m) and insert it on the filling connector taking care to push it
completely on.
– Lock the tube to connector with the plastic tie provided.
– Insert the other end of the tube on the tap of the filling tank.
– Make sure that the tube runs freely from the device to the filling tank, without being bent, crushed or obstructed in any way.
– Loosen the upper plug to facilitate the flow of water (also remove any gasket or under-plug);
– Open the tap on the filling tank.
e For this option setting, refer to chapter “Configuring the equipment –filling option”).
For additional information and advice about the correct connection of the sterilizer to the various water purification
systems, contact M.O.COM. Customer Service
Clip
Silicon pipe
Tap
Filling
tank
Clip
Teflon
