Rev. 1
Card Gr6-
4
DOOR POSITIONER
251#000003K0
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Access from the top and unscrew the nut (1) and remove the positioner (2);
3. Mount the new positioner, assembly all items proceeding in reverse order as
above;
4. Adjust the positioner, see Attachment A;
5. Perform a sterilization cycle.
