Mocom millennium B - SEQUENCE OF THE PROCESS; 2 nd pressure pulse - PP2

Rev. 1
Page 2-
15
2
nd
pressure pulse – PP2
After the second vacuum phase, steam is again injected into the sterilization chamber, with a relative rise in pressure (2nd PRESSURE PULSE.
1 134°C POROUS
2. PRESSURE PULSE
11.4 °C
0.72 bar 07:44
CHAMBER
Water
tank
DESCRIPTION
STATUSES
(P, t)
VP WP
EV1
(no)
EV2
(nc)
EV3
(nc)
EV4 EV5
(no)
EV6
(nc)
Fan
from –0,80 to 0,00 bar
(water entry 5” at –0,80
bar)
from +0,00 to +0,90 bar
2
nd
pressure pulse
from +0,90 to +1,00 bar
OFF ON ON OFF OFF OFF ON ON ON
