Rev. 1
Card Gr5-
9
MAINS SWITCH
A#2BP22400000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Disconnect the wire from the mains switch, fuse and mains filter board;
3. Replace the wiring, restore connections and assembly all items proceeding in
reverse order as above;
4. Run a sterilization cycle.
