SPARE PARTS
P/N Description Ref. Exploded view
A#6BM4380000 Standard supply kit D 1
C#1XP076000Y Tray 1 1
C#1BP459000Y Tray holder 2 1
S#TXX0080000 Tray extractor 3 1
A#0XP0010000 Bottle (2 liters) 4 1
110#000003W0 Drain pipe with quick coupling 5 1
472#00010000 Bacteriological filter 6 1
472#00040000 Filter LP1 7 1
C#1BP1660001 Side cover 8 1
C#1BP1650001 Top cover 9 1
C#1BH0060001 Single cover 9a 1
C#3BP1850000 Door cover 10 1
C#5BP2550000 Thermal printer “Fenix type” 11a 1
C#5BP4630000 Thermal printer “Custom type” 11b 1
S#CBP0010000 Thermal paper roll 11c 1
C#3BP1840000 Printer box cover 12 1
230#B04L14K0 Pin 4x20 13 1
420#00070000 Main switch 14 1
C#3BP1830000 Plastic front frame 15 1
C#5BP1230000 LCD Display 16 1
C#6BM1630000 Keyboard 17 1
C#6BM1890100 Millennium B adhesive label 18 1
