Mocom millennium B - Page 279

Rev. 1
Page 4-
13
P/N Description Ref. Exploded view
C#3BP2790000 Plastic plug 18a 1
472#00010000 Bacteriological filter 19 1
C#1BP153000M Left bar 20 1
C#1BP152000M Right bar 21 1
C#4BP2740000 Thermal insulating panel 22 2
C#0BP260000P Aluminum die-casting door 23 2
C#7BP2640000 Spring 24 2
C#0BP060000Z Nitrided fork 25 2
490#00050000 Bush 26 2
C#0BP0500000 Fork pin 27 2
203#C06L30K0 Screw 6x30 28 2
C#0BP079000N Door adjustment screw-sleeve 29 2
C#4BP2160000 Thermal insulating disk 30 2
A#1BP027000Y Inner dish 31 2
480#00050000 Dish gasket 32 2
C#0BP2720000 Hinge pin 33 2
A#1BP3380000 Hinge 34 2
A#1BP002000Y Chamber 35 2
C#0BP0430000 Closing pin 36 2
A#1BP2710000 Closing block 37 2
403#00010000 Gear-motor 38 2
232#A03L25K0 Pin 3x25 39 2
C#0BP0450000 Gear-motor coupling 40 2
C#0BP0460000 Intermediate coupling 41 2
