Rev. 1
Page 4-
14
P/N Description Ref. Exploded view
C#0BP0590000 Hook 42 2
433#00010000 Micro-switch 43 2
433#00010000 Micro-switch 44 2
433#00040000 Micro-switch (wheel pin) 45 2
286#00160000 Thermal probe bush 46 2
286#0014000N Thermal probe nut 47 2
430#00190000 Thermal probe PT1000 48 2
410#00140000 Band heating resistor 1700W 49 2
430#00180000 Thermal probe PT1000 50 2
430#00140000 Thermostat 51 2
C#4BP2140100 Chamber thermal insulating panel 52 2
C#4BP2150000 Rear thermal insulating panel 53 2
A#0BP2900000 Reservoir assembly 54 3
C#3BP1700000 Main/recovery reservoirs 54a 3
432#00060000 Float (MAX – recovery reservoir) 54b 3
432#00050000 Float (MAX/MIN – main reservoir) 54c 3
C#1BP146000M Reservoir middle bar 55 3
A#0BP3060000 Transformer assembly 56 3
412#00040000 Mains transformer 56a 3
C#1BP161000M Transformer bracket 56b 3
431#00060000 Pressure switch 57 3
C#1BP125000M Pressure switch bracket 58 3
260#000009MN Fast pipe coupling connector 59 3
431#00080000 Pressure transducer 60 3
