Rev. 1
Card Gr5-
10
POWER SUPPLY
A#2BP22900000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Disconnect the wire from the power and filter boards;
3. Replace the wiring, restore connections and assembly all items proceeding in
reverse order as above;
4. Run a sterilization cycle.
