Rev. 1

Card Gr2-

EV3 VALVE / COIL / SHAFT

401#00230000

EV3 ASSEMBLY

A#0BP2910000

EV2 – EV3 ASSEMBLY

A#0BP2830000

Before servicing, switch off the equipment and unplug the power

supply cable from the mains socket

1. Remove the covers (see card Gr7-1 );

2. Remove the wiring and the sheathed pipes from the valve;

3. Remove the group EV2/EV3 from the support;

4. Disassembly the group EV3 as necessary (see figure) and replace the

involved part;

5. Remount all parts, restore connections proceeding in reverse order as above;

6. Run a sterilization cycle.
