Rev. 1
Page 2-
22
Ventilation
When the drying phase is finished, it is followed by a VENTILATION phase in which fresh sterile air is injected, while maintaining a vacuum in the
chamber, to eliminate condensate and cool the load:
1 134°C POROUS
VENTILATION
84.4 °C
-0.77 bar 26:51
Water
tank
DESCRIPTION
STATUSES
(P, t)
VP WP
EV1
(no)
EV2
(nc)
EV3
(nc)
EV4
EV5
(no)
EV6
(nc)
Fan
Ventilation from -0,50/0,80 to -0,45 bar ON OFF OFF OFF ON ON OFF OFF ON
