Rev. 1
Card Gr6-
1
DOOR GASKET
480#00050000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Open the door;
2. Remove the gasket by hands;
3. Clean the gasket seat;
4. Arrange the new gasket as shown in the figure (top/bottom, left/right,
intermediate points);
5. Perform a sterilization cycle.
